Slate – Grey Green – Grey, slightly blue – Natural

Grey Green – Grey, slightly blue – Natural

¹ – Package without carton box
² – natural/natural finishing, without carton box

Standardized Dimensions

Standard Dimensions Available
Sizes Thickness
Millimeters(mm) Millimeters(mm)
100×100 | 150×150 | 150×300 | 150×600
200×200 | 200×300 | 200×400 | 200×600
250×250 | 250×500 | 300×300 | 300×600
400×400
6~9 | 8~11 | 10~13 | 14~17
18~23 | 24~27 | 28~32
8 | 10 | 12 | 15 | 20 | 25 | 30
400×600 | 450×450 | 500×500 | 600×600 10~13 | 8~11 | 14~17 | 18~23
24~27 | 28~32
8 | 10 | 12 | 15 | 20 | 25 | 30
300×900 | 800×400 10~13 | 14~17 | 18~23 | 24~27 | 28~32
10 | 12 | 15 | 20 | 25 | 30
600×800 | 600×900 | 700×700
800×800 | 1000×500
14 ~ 17 | 18 ~ 23 | 24 ~ 27 | 28 ~ 32
15 | 20 | 25 | 30
280×280 6~9 | 8~11 | 10~13 | 14~17
10 | 12 | 15
600×800 | 600×900 | 700×700 | 800×800
1000×500
18~23 | 24~27 | 28~32
20 | 25 | 30

Jobs Preferences

Best Uses
Arremate superior de muro Paisagismo
Bancadas de cozinha Peitoril de janela
Bancadas de pia Pisos
Bancos Prateleiras
Barretes Revestimento de parede
Colunas de mesas Rodapé
Divisórias Roda-bancada
Escadas [degrau | espelho | patamar] Soleira de porta
Filetes Tampos de mesas
Mosaicos Telhado

Finishing

Finishings
Tumbled | Calibrated Tumbled  | Natural
Brushed | Calibrated Brushed | Calibrated | Beveled Edges
Natural | Calibrated Natural | Calibrated | Beveled Edges
Natural | Natural  Honed|Calibrated

Recommendations

Recommendations
Application of a good quality sealer, both in the surfaces and sides, is strongly recommended.

Combinations

Combinations
One can obtain marvellous aesthetical and artistical results when combining the Grey Slate with other colors, such as black, purple, green and rusty, as well as mizing different sizes.

Care, Conservation and Maintenance

Care, Upkeep and Maintenance
After installation, thorough cleaning must be carried out to remove excess grout, cement, stains, dust, soil and other kinds of dirt.
All excess grout, cement or paste must removed and cleaned from joints.
For cleaning, only clean water and neutral detergents and other kinds of cleaning materials.
Cleaning must be carried out immediately after installation, before grout, cement and other kinds of setting materials are dry.
Acids, whether pure or diluted, should never be used
Only grout, cement, sealants, impregnators and cleaning materials from reliable manufacturers should be used.
The selected sealant, whether water-based or solvent-based, must be able to enhance the color and texture of the stone and make it impervious to oil, grease, fat, dirty water, and stains.
Floor wax or polishing wax should never be used on slate since it alters the color of the stone and makes it more prone to the accumulation of dust and dirt

Packing

With Carton Boxes in wooden crates
Dimensions
(mm)
Quantity Weight
(kg)
Container 20ft 27t
dimensions thickness per box net gross crates tiles
100×100 10 5346 1445 1510 18 96228
100×400 10 1540 1555 1620 16.5 23760
150×150 10 2376 1545 1510 18 42768
150×300 10 1188 1445 1510 18 21384
200×200 10 1440 1555 1620 16.5 23760
200×400 10 720 1555 1620 16.5 11880
300×300 10 594 1445 1510 18 10692
300×600 10 270 1330 1390 19.5 5265
300×300 8 702 1355 1420 19 13338
400×400 8 448 1555 1620 16.5 7392
400×400 10 360 1555 1620 16.5 5940
400×600 10 200 1310 1370 20 4000
600×600 12 108 1145 1200 22.5 2430
600×600 12 81 950 1010 26.5 2146



Without carton boxes in wooden crates
Dimensions
(mm)
Quantity Weight
(kg)
Container 20ft 27t
dimensions thickness per box net gross crates tiles
300×600 10 300 1460 1520 18 5400
300×600 20 150 1460 1520 18 2700
300×300 10 600 146 1520 18 10800
400×600 10 220 1440 1500 18 3960
400×400 10 400 1735 1800 15 6000
600X600 10 132 1265 1330 20 2706
600X600 12 110 1235 1300 21 2310
600X600 15 89 1285 1350 20 1780
500×500 10 200 1370 1435 19 3800



Natural/natural without carton boxes in wooden crates
Dimensions
(mm)
Quantity Weight
(kg)
Container 20ft 27t
dimensions thickness per box net gross crates tiles
300×600 07~10 310 1460 1520 18 5580
300×600 08~12 300 1460 1520 18 5400
400×400 07~10 464 1735 1800 15 6960
400×400 08~12 400 1735 1800 15 6000
400×600 07~10 265 1555 1620 16.5 4372



Dimensions
(mm)
Dimensions of the crate
(m)
dimensions thickness lenght width height
100×100 10 1,05 1,15 0,78
100×400 10 0,93 1,15 1,00
150×150 10 1,05 1,15 0,78
150×300 10 1,05 1,15 0,78
200×200 10 0,93 1,15 1,00
200×400 10 0,93 1,15 1,00
300×300 10 1,05 1,15 0,78
300×600 10 | 20 1,05 1,15 0,75
300×600² 7~10 | 8~12 1,08 1,15 0,78
300×300 8 1,05 1,15 0,78
400×400 8 | 10 0,93 1,15 1,00
400×400 ² 7~10 | 8~12 0,93 1,15 1,00
400×600 10 0,94 1,15 0,78
400×600 ¹ 10 1,05 1,15 0,78
400×600 ² 7~10 1,08 1,15 0,78
500×500 ¹ 10 1,13 1,15 0,76
600×600 10 | 12 0,95 1,15 0,78
600×600 ¹ 10 | 12 | 15 1,08 1,15 0,78
